PFA FULL LINED GLOBE VALVE
- Model Number: J41F46
- Brand Name: YFM
- Place of Origin: Zhejiang, China
- Minimum Order Quantity: 1
- Supply Capacity: 10000/month
- Payment: T/T
- MemberShip: Gold Member
- Inquiry Now
J41F46 PFA FULL LINED GLOBE VALVE Description
PFA Lined Globe Valve ansi Chemical
Technical Specification
Design and Manufacture Standard: ASME B16.34, HG/T 3704
Face-to-face Dimension: ASME B16.10, GB/T 12221
Flange Standard: ASME B 16.5, GB/T 9119, DIN, JIS
Inspection and Testing: API 598, GB/T 13927
Product Specification
Body Material: WCB, ASTM A395, CF8, CF8M
Lining Material: PFA, FEP, PTFE
Nominal Diameter: 1/2"-14"(DN15~DN350)
Pressure Range: Class150, PN10, PN16
Operation Method: Manual, Worn gear, Electric, Pneumatic actuator
| SIZE | 1/2"-16" |
|---|---|
| BODY MATERIAL | WCB, ASTM A395 , CF8 ,CF8M |
| PRESSURE | PN1.0 PN1.6 150LB |
| SEAT | PFA, FEP, PTFE |
