Hydroman Heavy Duty Submersible Sand Pumps
- Model Number: Heavy Duty Submersible Sand Pumps
- Brand Name: Hydroman™
- Place of Origin: Hebei, China
- Minimum Order Quantity: 1set
- Supply Capacity: 6000sets/month
- Payment: T/T
- MemberShip: Free Member
- Inquiry Now
Heavy Duty Submersible Sand Pumps Hydroman Heavy Duty Submersible Sand Pumps Description
Hydroman™ TSQ Heavy Duty Submersible Sand Pumps are specially suitable to be used for pumping sand. Sand is pumped mixed with water up to 70% of solids by weight. The mixture of liquid and particles of sand and gravel is pumped in a procedure often used as a convenient way of handling sand and gravel. Hydroman submersible sand pumps can be used in sand and gravel extraction, dredging of rivers, harbors and marines maintenance or construction, beach reclamation, filling of Geotubes, among others.
Design Features:
▪ Hydroman submersible electric motors are all Class H insulated and have a minimum 1.25 service factor.
▪ Hydroman Submersible Sand Pumps are equipped with a unique lip seal system to prevent material from penetrating the seal.
▪ High quality abrasion resistance materials ensure long life of all components.
▪ Temperature sensor, embedded in the electric motor, and Moisture sensor, in the oil chamber, are available options to protect the submersible pump in the most demanding application.
▪ Adjustable Hi-Chrome suction side Wear Plate maintains maximum performance for extended periods by a simple adjustment of the gap between the wear plate and the impeller.
▪ Replaceable wear parts: casings, impellers, wear plates all can be replaced independently.
▪ Lube Oil Inspection Ports: a wide angle port outside the submersible pump ensures easy inspection of shaft seal oil levels as well as providing easy access for oil replacement.
▪ The excavating action is created by the Hi-Chrome agitator blades that lift settled sediments which then get sucked into the submersible pump, creating a continuous flow of concentrated sand.
