Handwheel knife gate valve PN10 DN200

Handwheel knife gate valve PN10 DN200
  • Model Number: GLK73
  • Brand Name: Guanli Valve
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 1 Set
  • Supply Capacity: 10000 Sets/month
  • Payment: Visa, T/T, L/C, Western Union
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

GLK73 Handwheel knife gate valve PN10 DN200 Description

Handwheel Wafer knife gate valve PN10 DN200

Valve body: DUCTILE IRON GGG40+EPOXY BAKED,

Gate: SS304, Seat: EPDM,

Retainer: SS304,

Yoke: A36+EPOXY BAKED,

Packing gland: WCB+EPOXY BAKED,

Stem: SS420, Stem nut: BRASS

Material Ductile iron
Pressure Low Pressure
Temperature of Media Low Temperature
Media Corrosive medium,pulp,water
Application General
